1.Application:
Applicable for foam and paper tube.And cloth stripes/stretch cling film/BOPP/PVC/PE/masking paper tape/ double side tape/ kraft tape/ foam tape/cloth tape/electrical tape also suitable for.
2.Features:
A.Can cut 10 differant kinds of width once on one roll without stop the machine for width setting.
B.High hardness, good abrasion linear rails with small gap, high hardness ball screwlead adopted to ensures stability and high precision.
C. Operating Panel: All functions are operated on the Human-computer panel.
D. Cutting Roll Positioning System: Cutting roll positioning is controlled by the servo motor.
E. Automatic Circular Blade Angle Adjusting
F.Main Shafe and Effective Cut Width could be customized accoring to buyers' reqiurement.
3.Technical Parameters:
Model | XW-706 |
Work Width(mm) | 1300/1600 |
Max Cut Diameter(mm) | 350 |
Min Cut Width(mm) | 1.0 |
Paper Core I.D(mm) | 25.4-76.2 |
Main Power | 4kw-6 |
Blade Power | 2.2kw-6 |
Power Supply | 380V 50HZ |
Dimension (LxWxH) | 3150X1450X1550 |
